物理特征

外形尺寸:

40 mm x 42 mm x 24 mm

重量:

68 g (2.4 oz.)

探測器

探測器:

ELIS1024, 1024 pixel linear CMOS

探測范圍:

200-1100 m (uncoated)

像元/尺寸:

1024, 7.8 x 125 µm

光譜特性

波長范圍:

VIS (350-800 nm), NIR (650-1100 nm)

光學分辨率:

1.5 nm FWHM (w/ 25 µm slit)

信噪比:

>1500:1 (maximum signal)

A/D:

14 bits

暗噪聲:

<3 counts RMS

動態范圍:

6x109 (system, 10s maximum integration), 5600 single acquisition

積分時間:

10 µs - 10 s

雜散光:

0.5% max deviation from best fit line (10-90% saturation)

最大暗電流:

75 counts/second
